misol
misol
In stock, ready to ship
Use this text to display some key features of the products
* Wireless 433Mhz (from outdoor sensor to console display)，max. Distance: 100m（330ft)
* WiFi connection (console connect to WiFi 2.4Ghz)
* TFT LCD full color display
* History data record in the console (receiver), can be copied to micro sd card (recommend 16GB or less).
* Indoor temperature, humidity, air pressure measured by display console in-built sensor.
* Wireless Outdoor Solar Powered 7-in-1 Weather Sensor measures wind speed, wind direction, temperature, humidity, rainfall, UV and Light.
* Dual-power supply for outdoor sensor: Solar power for inner super capacitor + Backup batteries (AA 1.5V)
* Get Live data instantly
* Support servers: Weathercloud, Ecowitt.net, Wunderground, WOW or third part server. Easy integration to 3rd party system
Package includes:
1) Display Console
2) Outdoor sensor arrange(Thermo-hygrometer / Rain Gauge / Wind Speed / Wind direction /Transmitter)
3) 5V DC adaptor (a USB to 2.5*0.7mm DC 5V power plug connector cable included)
1. Wind Vane
2. Wind Speed Sensor
3. UV sensor/Light sensor
4. Solar panel
5. Rain collector
6. Thermo-hygro sensor
7. Bubble level
8. U-Bolt
9.LED Indicator
10. Battery door
11. Reset button
|
Outdoor sensor |
Specification |
|
Transmission distance（max.) |
100m(330ft), in the open field, no obstacle, no signal interference. |
|
RF Frequency |
433MHz |
|
Temperature range |
-40°C – 60°C (-40°F - 140°F) |
|
Temperature accuracy |
± 1°C, or ± 1.8°F |
|
Temperature resolution |
0.1°C, or 0.2°F |
|
Humidity range |
1% ~ 99% |
|
Humidity accuracy |
±5% |
|
Humidity resolution |
1% |
|
Rain volume display range |
0 – 9999 mm |
|
Rain volume accuracy |
± 10% |
|
Rain volume resolution |
0.3 mm (for volume < 1,000 mm) |
|
Wind speed range |
0 – 50 m/s (0 ~ 100mph) |
|
Wind speed accuracy |
± 1 m/s (speed < 5 m/s) |
|
Wind direction accuracy |
±15° |
|
UV-Index range |
1 - 15 |
|
Light range |
0 – 200 kLux |
|
Light accuracy |
± 25% |
|
Sensor reporting interval |
16s |
|
Light accuracy |
± 25% |
|
Sensor reporting interval |
16s |
|
Indoor sensor |
Specification |
|
Temperature range |
-10°C – 60°C (14°F - 140°F) |
|
Temperature resolution |
0.1°C, or 0.1°F |
|
Humidity range |
1% ~ 99% |
|
Humidity resolution |
1% |
|
Barometric pressure range |
300 – 1,100 hPa (8.85 – 32.5 inHg) |
|
Barometric pressure accuracy |
± 5 hPa in 700 – 1,100 hPa range |
|
Barometric pressure resolution |
0.1 hPa (0.01 inHg) |
|
Sensor reporting interval |
60 seconds |
|
Alarm Duration |
120 seconds |
|
Power |
Specification |
|
Base station/console |
5V 1A DC Adapter (a USB to 2.5*0.7mm DC 5V power plug connector cable included) |
|
Outdoor sensor |
Solar panel (built-in) 6.5V/4mA |
|
Outdoor sensor (backup) |
2 x AA 1.5V battery (not included) |
Remark: The primary power source for the outdoor sensor is the solar panel. When available solar power (light over recent period) is insufficient, the batteries will be used. In outdoor climates that frequently have sustained temperatures below 0°C (or 32°F) the use of Lithium batteries is strongly suggested as these are performing better than Alkaline batteries under such circumstances.
